| Force Capacity | 1000 N (225 lbf) | ||
| Max. Crosshead Travel, Standard Travel (Between the Eye Ends) | 500 mm (19.7 in) | ||
| Max. Crosshead Travel, Extended Travel (Between the Eye Ends) | 800 mm (31.5 in) | ||
| Crosshead Speed Range | 0.01-2032 mm/min (0.0004-80 in/min) | ||
| Max. Return Speed | 2032 mm/min (80 in/min) | ||
| Speed Accuracy (Unloaded) | +/-0.2% of selected speed from 2% to 100% of max. speed | ||
| Min. Load Resolution (Load Cell Specific) | 0.0001N (2.2x10-5 lbf) | ||
| Load Cell Accuracy | +/-0.5% from 1% to 100% of load cell value | ||
| Extension Resolution | |||
| Data Sampling Rate | 8kHz | ||
| Distance accuracy | +/-0.2% of reading from 2% to 100% of max. travel | ||
| Load Measuring System | EN ISO 7500:2004, Class 0.5 ASTM E4 | ||
| Relative Humidity | 20% to 85% | ||
| Operating Temperature | +5 to 35°C (41 to 95°F) | ||
| Storage Temperature | -17 to 54°C (0 to 130°F) | ||
| Supply Voltage (+/- 10%) | 115VAC/230VAC, 50-60Hz | ||
| Max. Power Requirement | 150VA |
