Instrument test range: |
From the element between aluminum Al-uranium U RoHS restricted harmful elements Pb/Hg/Cd/Cr/Br + halogen Alloy: copper, iron alloy, nickel alloy, tin alloy, titanium alloy, precious metal Coating: Ag/Sn/Au/Ni—Cu, Cr/Zn/Ni/Ag/—Fe |
|
Element detection range |
1ppm-99.99% |
|
Sample type: |
Solid (plating), liquid (component) |
|
Testing time: |
60s-200s(Software automatic adjustment) |
|
RoHS and halogen test accuracy |
Over 100ppm：10% 20-100ppm：±5ppm Under 20ppm：±5ppm |
|
RoHS halogen detection limit |
Pb/Cd/Cr/Hg/Br≤2ppm，Cl≤26ppm |
|
Camera positioning system: |
12 million true pixel high-definition positioning system; |
|
X-ray tube： |
Model：KEW Place of production: Shanghai Window material: metal beryllium Life spend: more than 30000 hours |
|
Detector： |
Model：X55-SDD Place of production：America - Amptek Electric cooling SDD detector, FW7 version Resolution 125ev±5 1mil beryllium window thickness |
|
High Voltage： |
Model：X50P50 Manufacturer: CFAN 0-50kev, 0-2mA maximum 50W |
|
High voltage protection measures |
Overvoltage self-protection, self-recovery |
|
X-ray collimation system |
0.3 or 1,3,5 total 3 groups, the smallest configurable 0.3mm |
|
X fluorescence filter system |
12 kinds of composite filters to meet various testing needs |
|
Integrated industrial computer: (All-in-one computer) |
Operating system: Windows7 (no external computer required) |
|
Working temperature: |
Temperature: 15-30℃; Humidity: ≤75% (no condensation) |
|
Input power: |
AC 220V±15%，50Hz |
|
Instrument size: |
450(L)×410(W)×400(H) |
|
Test sample cavity size: |
350(L)×300(W)×100(H) |
|
Radiation protection standards: |
Much higher than the national standard GB18871-2002 GBZ115-2002 standard |
